LEVEL 2 - MAINTENANCE SERVICING
Here is a full summary of all the modules and lessons found in Level 2 of this course.
Maintenance Servicing of the basic mechanical watch.
Get instant access
Each lesson and topic is presented to you in full high definition 1080p video. There are no time limits, you can pause your learning and pick up from where you left off at any time in the future. You have instant access to the course once you have enrolled.
Over 4 Hours of Crystal Clear HD Video Teaching
All the images you find below, and on this whole web page are actual screen shots from the lesson videos. Once you have gained access to the course level, you will have access to it for as long as you need – there are no time limits. This will allow you to go over and review all the course content as many times as you like, even after you have completed the course.
What You Will Learn...
Level 2 of this course builds upon the foundations set in level 1. In particular you will gain a greater understanding of the anatomy of the watch movement as we strip the basic mechanical watch to pieces, clean the components, check for wear or damage, re-assemble, lubricate and re-calibrate.
HOW TO SAFELY STRIP A WATCH MOVEMENT TO PIECES - AND RE-ASSEMBLE IT
This level contains all the information you need, from providing a guideline procedure for dismantling the movement, to choosing the correct lubricant for the various friction points as you re-assemble it. And most importantly, how to regulate and test the watch once re-assembled and lubricated in order to get the best performance out of the watch.
COURSE CONTENT
C2.1.0 STRIPPING DOWN THE MOVEMENT
There are no specific rules to the order a watch is stripped to pieces. However, it is important to know that the potential to cause damage is greater unless you follow a basic guideline.
c2.0.1 Using & Maintaining Tweezers
In order to reduce the risk of watch parts getting lost, it is advisable to choose high quality tweezers and to maintain the tweezer tips. When new to watch repair you should spend quite a bit of time practicing with your tweezers and developing your technique
c2.0.2 Using & Maintaining Screwdrivers
Watchmakers screwdrivers come in sets of various different sizes. Choosing a suitable size for the screw you wish to loosen, or tighten, will reduce the risk of damaging the screw head or slot. You should choose a screwdriver with a blade width slightly smaller than the diameter of the screw head. If the blade is to large then you risk damaging, or scoring the material around the screw
c2.1.1 Removing The Movement From The Watch Case
It is never a good idea to start stripping a watch movement down when it is still in it’s watch case. The movement may not be fully secure and you will run the risk of damaging the dial as you apply downwards pressure on certain screws
c2.1.2 Removing The Dial and Hands
When working with watch movements, it is the watch repairers duty to take extreme care not to damage or scratch any of the parts even if they are not visible. However, when working with the dial and hands, this duty should become an obsession
c2.1.3 Removing Power From The Mainspring
Releasing any power in the mainspring is a very important prerequisite to stripping down any watch or clock movement. Failing to perform this step can cause damage to your movement in several different ways
c2.1.4 Removing The Balance
Arguably the most sensitive part of the watch movement is the balance assembly, and in particular, the balance spring. Therefore it is recommended that this should be the first component to remove and set safely aside
c2.1.5 Removing The Motion Work
Removing the Motion Work before removing the Train Wheels is a great example of where observing this guideline is important because the Cannon Pinion is friction fitted to the Centre Wheel
c2.1.6 Removing The Pallets
The Pallet fork is located under the balance and is secured with a bridge which needs to be removed first. The pallet staff pivots are very fine and if you are not careful when removing the Pallets then you run a real risk of them breaking
c2.1.7 Removing The Barrel and Train Wheel Bridges
In the previous lesson where we removed the power from the mainspring, we removed the Ratchet Wheel at that time as this ensures that there is no power still in the mainspring. Before removing the Barrel Bridge, it is also advisable to remove the click, click spring and the crown wheel as this will be easier to do whilst the barrel bridge is secured to the lower plate
c2.1.8 Removing The Train Wheels
Now that we have removed the train wheel and barrel bridges, the train wheels and barrel are exposed and can be removed
c2.1.9 Removing The Keyless Work
The final step in our guideline for stripping down the watch movement is to remove the Keyless Works components
C2.2.0 INSPECTING THE WATCH PARTS
Now that you have stripped the movement down it is highly recommended that you inspect each part individually.
Watches are designed to run for a very long time, sometimes many years, without the need for service. However, some watch owners will tend to have an “if its’s not broken then it doesn’t need repair” attitude towards their timepiece
c2.2.1 Inspecting Jewels And Pivot Holes
Servicing and maintaining watches does not end with stripping the movement to pieces, cleaning, lubrication and re-assembling. A large part of your focus when working on any movement should be devoted to observation
c2.2.2 Checking For and Dealing With Rust
Rust is most definitely an issue you will come across at some point when you start servicing and maintaining watch movements
c2.2.3 Checking For Damage and Wear
There are three basic stages for performing a maintenance service with any watch movement. Stripping it down, cleaning it and then rebuilding it. During all three of these stages, it is good practice to be on the constant lookout for issues which will affect the good running of the watch
C2.3.0 CLEANING TECHNIQUES
Once the movement has been taken to pieces and you have inspected all the parts, its now time to proceed with cleaning those parts.
There are various methods to cleaning watch movement components which may result in differing levels of cleanliness. In fact, in ideal circumstances and for optimal performance of the movement once it is re-assembled and lubricated, the goal is to clean the movement to a clinical level
c2.3.1 Cleaning By Hand
When you are first starting out with watch repair, it may not be practical or even advisable to invest in expensive equipment such as ultrasonic machines or watch cleaning machines
c2.3.2 Using An Ultrasonic Bath
When cleaning your watch movement components by hand, you may find it useful to agitate the parts whilst they are soaking in the cleaning fluid with an ultrasonic bath
c2.3.3 Watch Cleaning Machine
Using a dedicated watch cleaning machine will both increase your productivity and arguably give you better results when cleaning watch components. You will still need to be able to clean certain parts by hand, but investing in a watch cleaning machine will be a natural step forward as you progress in watch repair
C2.4.0 LUBRICATION AND RE-ASSEMBLY
Now we shall look at lubrication and the re-assembly of the basic mechanical watch movement. You may observe that I have not separated these two subjects, this is because the lubrication and re-assembly of a watch movement, for the most part, will go hand in hand
c2.4.1 Choosing Correct Lubricant
Many modern watch movement calibers will have a corresponding data sheet with part numbers, illustrations and often an oiling chart. These can be extremely useful to help you determine the correct lubricant for a particular friction point
c2.4.2 Lubrication Techniques
Before we get started with re-assembly, lets take a look at some principles in the lubrication of friction points in mechanical watch movements.
For the most part, you will need to lubricate where any two components come into contact and interact with each other…
c2.4.3 Re-Assembling The Watch Movement
Now we are ready to start re-assembling and lubricating the movement. You may remember, we previously talked about a guideline procedure for stripping a movement to pieces
c2.4.4 Assemble The Train of Wheels
If you made notes or took photographs whilst you were stripping the movement down, this should be a relatively simple task. Assembling the train of wheels is a simple case of placing the wheels the correct way up and in the correct order
c2.4.5 Assemble The Going Barrel
When re-assembling the barrel you have to make a choice wether to use the existing mainspring which you removed when you stripped the watch down, or to replace it with a new one
c2.4.6 Using A Mainspring Winder
Mainspring winders are quite an expensive investment but very useful to have in your tool kit. Depending on the size of the set you purchase, there will be many different drums to suit the size of barrel you wish to fit the spring into. Choose a drum which is slightly smaller than the inside diameter of your barrel and remove the crank…
c2.4.7 Fitting the Barrel Arbor and Lid
Whichever method you have chosen in order to replace the mainspring you should now have your mainspring correctly seated in the barrel and it’s time to install the barrel arbor. Check the direction of the hook on the barrel arbor and match it to the hole on the inner coil of the mainspring
c2.4.8 Assemble The Barrel Bridge
With the Unitas movement we are working with, you will notice that the barrel bridge not only secures the Going Barrel, but also the Centre Wheel. Before fitting the barrel bridge, make sure the train of wheels spins freely by…
c2.4.9 Assemble The Motion & Keyless Works
Now it’s time to re-assemble the motion works and the keyless works. You may recall, we fitted the setting lever screw prior to placing the barrel bridge. Now we can fit the setting lever to the screw, and it must be noted that this may take a little practice
c2.4.10 Assemble The Escapement & Balance
We have now completed the assembly of the Train of Wheels, The Going Barrel, The Motion Works and The Keyless Works. Now it’s time to install the escapement and balance assembly
c2.4.11 Lubricating The Balance End Stones
The final stage in re-assembling the watch movement will be to lubricate the balance end-stones. Depending on how you cleaned the movement it may be necessary to clean them at this stage also
C2.5.0 TESTING & TIMING
With the watch movement fully assembled and running, it is now time to test it’s operation and regulate it’s timekeeping.
If there are any issues with the watch movement then these issues will be identified during the testing stage and so it is very important not to skip this step
c2.5.1 De-Magnetising The Movement
After the watch movement parts have been exposed to potential magnetic fields, for example, emitted by a watch cleaning machine motor, the movement will need to be de-magnetised
c2.5.2 The basics of regulating a movement
If a watch does not maintain a reasonable expectation of time-keeping, then it’s does not serve much of a purpose. And of course, following a full strip down and re-assembly along with fresh lubrication applied and perhaps even replacement of worn parts, the time keeping of the movement will need to be assessed and adjusted accordingly
c2.5.3 Adjusting The Movement Rate
As mentioned before, the rate of the watch is determined by the speed, or rate, at which a beat occurs as compared to the preceding beat. This rate is governed by the balance assembly and in particular, the diameter and weight of the balance wheel, and the strength and length of the balance spring….
c2.5.4 Setting The Movement In Beat
As the balance oscillates, it interacts with the pallet fork twice. These are called vibrations, or beats. Effectively it is the ‘tictoc’ sound you hear with any mechanical watch movement
c2.5.5 Adjusting For Positional Error
When timing a watch you would aim to test the rate in several different positions. As an example, if a watch movement is moved from a dial-up or dial-down position to a pendant, or…
c2.5.6 Testing a Movement
Now that you have adjusted the rate of your watch movement, it is very important to put the watch through various stages of testing. The first test will be before you re-case the movement….
FREE BONUS VIDEOS
As a commitment to giving you continuous value for money, you now get these extra bonus videos for FREE when you complete Level 2. This is an on-going project and there will be more coming, again – at no extra charge when they are available.
SPECIAL OFFERS
Discounted Bundle
Would you like to save money? Purchase all three levels of the Watch Repair Course in one transaction and save $189! And even better – you still get a nice 30% discount should you wish to enrol on further levels as and when they are released.
Free Demo
Would you like a better example of how the course works? Would you like to view an example of the course with 5 FREE LESSONS? Are you unsure if the videos will play on your device? No problem – simply sign up for the instant access free demo and start streaming the demo content today!
